Tech Specs

Description

· Charakteristisches Design Rotkupfer-Dreiecksemblem und Aluminium-Artisan-Tastenkappe für ein elegantes, unverwechselbares Frontprofil.

· Vollständig anpassbar Hot-Swap-Schalter mit ANSI/ISO-Layout-Unterstützung und Tri-Mode-Konnektivität für ultimative Flexibilität.

· Premium-Materialien Kupfer-Rückgewicht mit matter Oberfläche für Langlebigkeit, Fingerabdruckresistenz und zeitlose Eleganz.

· Ikonisches Tippgefühl Sylva-Schalter bieten ein geschmeidiges, harmonisches Tipperlebnis, inspiriert von der Natur.

· Zeitloser Stil Klassische Panels, Double-Shot-PBT-Tastenkappen und elegante Farboptionen machen jedes Setup einzigartig.

Specifications
Keyboard format

80%

Keyboard layout

ANSI / Qwerty

Pcb
1,6mm Hot-Swap
Plate
1,5mm PC-Platte
Keycaps

PBT Dye-sublimated keycaps

System compatibility

Windows
Mac
Linux

Programming support

VIA
QMK

Size
359mm × 136mm × 19mm
Stabilizer
Gateron Stabilisatoren
Switches
Switch type
Mechanische Schalter-Tastatur
Keyboard switches

Luminkey Sylva Linear Switches

Switches specifications

· Hersteller: GATERON

· Schaltertyp: Linear

· Gehäuse: Nylon

· Stempel: POM

· Boden: Nylon

· Feder: Edelstahl (vergoldet)

· Gesamthub: 3,7±0,3mm

· Betätigungskraft: 48±gf

· Gesamthubkraft: 55±20gf

Connectivity
Polling rate

Wireless 2.4G: 1000Hz
Wired: 1000hz
Bluetooth: 125Hz

Low latency mode data

2 millisecond
3 millisecond
7 millisecond

Latency data

Wired: 2 millisecond
2.4G: 6 millisecond
Bluetooth: 40 millisecond

Dongle
Kabelgebunden: 1000Hz 2.4G: 1000Hz Kabellos: 125Hz
Design
Case material

6063 Aluminum

Badge
Kupfer
Typing angle

7 degrees

Mounting
Gasket Mount
Build Components

1*top case

1*bottom case

1*copper weight

1*Led Acrylic Sign

1*tri-mode hot-swappable pcb

1*type-c daughter board

1*plate

1*foam kit

1*switch puller&keycaps puller

1*screwdriver

1*USB cable

a set of stabilizer

a set of Astra switches

a set of keycaps

LUMINKEY 80 MK II Custom Mechanical Keyboard CNC Aluminum Case

LUMINKEY 80 MK II

QMK Tri-Mode • PCB Gasket Mount • Full CNC Aluminum Case • 7000mAh Battery
Video laden:
LUMINKEY 80 MK II VIA
DRIVER
VIA Custom Key Remapping
The LUMINKEY 80 MK II supports VIA remapping,
allowing you to customize every key with ease.
Create the perfect tool for your workflow and gaming experience.
VIA Key Remapping

LUMINKEY80 MK II

Tri-Mode - Wireless - Wired - Bluetooth

9009 Keycaps

Dye-Sublimated PBT Keycaps


Featuring classic OEM-profile dye-sublimated PBT keycaps, the LUMINKEY 80 MK II offers a comfortable and refined typing feel. The durable PBT material provides excellent wear resistance while maintaining a smooth, non-slippery surface for long-term use.

Glacier Blue & Navy Keycaps


Designed with a sophisticated blend of cyan, blue, and deep navy shades, these keycaps create a dynamic layered look while adding a premium touch to the keyboard.

WOB Keycaps

Featuring a deep and premium black
dye-sublimated molding design, these keycaps offer a versatile aesthetic that seamlessly blends with any color scheme. A timeless choice for creating your perfect custom keyboard build.

Change ANSI / ISO Layout Freely

Hot-swappable LUMINKEY80 MK II, easy to customize your style! (*ISO keycaps and LED indicator keycaps NOT included in the standard kit)

LUMINKEY 80 Series Internal Design

Through precise internal tuning and multiple foam layers, the LUMINKEY 80 MK II delivers a deeper, fuller sound signature with improved typing comfort and a more refined keystroke experience.

LUMINKEY80 MK II

LUMINKEY80

Spec for Astral Switches

LUMINKEY80 MK II Switches

  • LUMINKEY Astral Switches
  • Switch type: Linear
  • Housing Material: PC(top)/POM(bottom)
  • Stem:Pom
  • Operating force:45g±5gf
  • Total travel force:50g±5gf
  • Pretravel: 2.0mm±0.4mm
  • Total travel:3.5mm±0.2mm

Spec for Sylva switches

LUMINKEY80

Manufacturer: GATERON
· Switch type: Linear
· Cover: Nylon
· Stem: POM
· Bottom: Nylon
· Spring: Stainless steel (gold-plated)
· Total travel: 3.7±0.3mm
· Operating force: 48±gf
· Total travel force: 55±20gf

LUMINKEY 80 MK II Dimensions
Dimensions
Overall Width 360.1 mm
Overall Depth 137.5 mm
Front Height 17.7 mm
Typing Angle 8°
SPECIFICATION

LUMINKEY 80 MK II

Total Pre-built / Barebone Kit Keycaps PBT
Color E-Retro White / Ano Silver / Ano Red / Ano Green Profile OEM
Layout 80% ANSI / ISO PCB 1.6mm Tri-mode Hot-swappable PCB
System Windows / macOS / Linux Plate 1.5mm POM Plate
Structure Gasket Mount Stabilizer Plate-mounted Stabilizer
Case 6063 Aluminum Weight Aluminum + Stainless Steel
Finish Anodizing / Spray Coating RGB No Per-key RGB
Function Indicator Only
Switch Linear Switch Connection USB-C / Bluetooth / 2.4G
Battery 7000mAh Interface Type-C
Sound Package 3.5mm Poron Foam
0.5mm Bottom Pad
PET Sound Pad
2mm Hot-swap Foam
1mm Bottom Foam ×2
Accessories Type-C Cable
2.4G Dongle
Keycap & Switch Puller 2-in-1
Screwdriver
Spare Switch ×1
Spare Keycaps ×3
Dimension L360.1mm × W137.5mm
Front Height 17.7mm
Typing Angle 8°
  • 5 stars: 18 (90%)
  • 4 stars: 2 (10%)
  • 3 stars: 0 (0%)
  • 2 stars: 0 (0%)
  • 1 star: 0 (0%)
C
Chong H.C.
A really solid board

-10/10 sound if u really like a foam focused board
-Switches are really really smooth stock, 90% of the way there as compared to hand lubed switches
-Tri-mode works well
-the Gasket design makes it a pretty soft typing experience but not overly soft
-Finish on the case is 10/10 no problems
-Keycaps are of a generic colourway but the texture on them feel really pleasant
- Stabs are perfect lol

If you are willing to swap out the keycaps for GMK or something, in my subjective opinion its sounds gets better

S
S.K.

Love it

J
Jake
The best keyboard I've ever bought

It's a clear leap above entry level brands like Keychron that I had purchased before. The sound out of the box is amazing (especially the stabilizers) and I love the color of the Matcha Gray coating.

S
Sunho K.

[IN-STOCK] LUMINKEY80 80% Custom Mechanical Keyboard

M
Mauricio R.
Solid

Fantastic Sound, design, modability.

P
Peter V.
Premium!!!

The keeb feels and looks super premium. So happy I went with the beautiful red edition!
It is very hard to change the sound profile though I don't know why.

재
재휘 박.

Shipping is fast and I'm very satisfied with the product

S
Samuel B.
Best keyboard !

This is the best keyboard i've had in years ! So easy to customize and really good sounding too. 10/10 would recommend !

C
Chen L.

Great product, love it so far

P
Paolo C.
Excellent keyboard

It was my first experience on building a custom keyboard. With the Luminkey80 i didn't have any problem with my built, i only had to lube the stabilizers with krytox gpl205 g0, mounted akko cream black pro linear switches and GMK keycaps to have a gorgeous wonderfully sounding custom keyboard wich feels great on my fingers!

M
Maud O.
Decent keyboard, props for the solid ISO support.

First time buying such a fancy MX custom, I’m happy with my purchase and I’m thankful that you offer good ISO support.

It’s much better than other hot swap boards I’ve used before, switches feel solid, there’s nothing janky about the build, the carrying case is a nice touch too.

C
Clarence H.
Prebuilt Luminkey80

This is probably the best prebuilt keyboard I have ever tried. All the stabs were near perfect (just the spacebar needed a little work). If you want a solid TKL at this price point, the Luminkey80 is probably the best choice.

N
Nathan W.
Great quality package.

For the price I paid I believe that the quality of the board plus the extra included contents is of great value. Value aside, I do think that this is a great board and am very happy with how my build turned out. The lubrication of the stabilizers was good enough that I did not need to lube them myself as well. My only feedback is that I would like for Luminkey to provide more pictures of the colors in different lighting as the color of the case was not exactly as I thought it would be in person but I am still happy with it nonetheless.

N
Nicolae A.
Its a bang for the buck

Great price, begginer friendly, ready to go out of the box with almost perfectly lubed stabs, accessible price point, great customer support, consistently lubed switches and nice included keycaps, perfect finish and minimalist design.
Considering all that there are just a few points that would make this keyboard even better:
1. More mounting options (top-mount and maybe different gasket resistances)
2. More plate options (even alu plate is sold separatedly would be nice to have the option to include it instead of pc plate)
3. Since the pcb is non-flex cut it could use a full south facing rgb (having the backlight only for escape key doesnt really make any sense, i would even prefer separate led lights for caps lock / num lock and so on even without any led lights at all on the plate itself)
4. The design is really simple which allows the board to be at its pricepoint but a bit more character would make it stand out near competitors in the price range with that being said the design is really nice and simple
Even without all those nice-to-have points the Luminkey80 is near perfect for its price point. Could definately recommend it to someone who wants to get the custom experience with a in-stock keyboard.

V
Victor S.
Nice!

Good keyboard. Enjoy using it!

E
Ed A.
Amazing budget custom TKL

Nice board and easy to build. The only real quirk is that due to supporting multiple layouts, in ANSI mode the caps lock and backslash keys require the switches to be installed at 90 degree angles. This causes some keycaps to not sit flat (stepped caps lock in particular). It's subtle, but may bother some.

The sound profile is nice, but definitely benefits from Tempest tape mode.

These are just quibbles; I can't wait to buy this board in every new colour!

C
Christian L.B.
Almost perfect

Just a little stabs rattle. Solved with some more lub tho.

R
Ramses A.
Great build quality. Needs better documentation for what is the default keymap

Revising my review from 3 to 4 stars. As mentioned before, great build quality. I was able to remap the RCtrl key properly in VIA -- the fact that it is default set as Function should be documented up front! Literally, all product photos show RCtrl keycap rather than Function

Thank you for your purchase and reivew.
The RCtrl is the 'FN' key, kindly remap it to RCtrl by VIA if you prefer an RCtrl key.

S
Stetson Z.
Goated tkl

Good aesthetics, sound, and feel. Only thing that could have been better is more weight and plate options, and more colors. Great keeb

R
Rocky L.
Best value TKL board out there

One of the best values of entry level premium TKL boards, the only other board that compares is the QK80.
